| FRAMESET |
| Frame |
Orbea Avant Hydro disc, hydroformed triple butted aluminium, HS 1.5” ICR, BB68mm – BSC English, Thru Axle 12x142mm rear, thread M12x2 P1, Internal Cable Routing, SP 27.2mm, MMS system. |
| Fork |
Orbea carbon fork 2021, aluminium steerer, 1-1/8” head tube |
| Headset |
Acros Alloy 1-1/2” Internal Cable Routing |
| DRIVETRAIN |
| Crankset |
Shimano Claris R2000 34x50t |
| Shifters |
Shimano Claris ST-R2000 |
| Cassette |
Shimano HG50 11-32t 8-Speed |
| Rear Derailleur |
Shimano Claris RD-R2000-GS |
| Front Derailleur |
Shimano Claris FD-R2000-F |
| Chain |
KMC X8 |
| COCKPIT |
| Handlebar |
OC RP30-R Road Performance Riser, Reach 70, Drop 125, Rise 15, w/Di2 hole |
| Handlebar Plugs |
Orbea Eva |
| Stem |
OC RP21 Road Performance ICR, -6º, IFC01 Computer mount interface |
| BRAKES |
| Brakes |
Tektro MD-C550 Mechanical Disc |
| WHEELS |
| Wheels |
Orbea wheel: Corsa with 12mm E-Thru hubset Shimano RS470 28H |
| Rear Hub |
Orbea Thru Axle 12x142mm M12x2 P1 Solid |
| Front Hub |
Orbea Thru Axle 12x100mm M12x2 P1 Solid |
| Tyres |
Vittoria Zafiro V Rigid bead 700x28c |
| COMPONENTS |
| Seatpost |
Alloy 27.2 Offset 20 |
| Saddle |
Fizik Aliante R5 |
| Mudguard |
N/A |
