SPECIFICATIONS
FRAMESET
FRAME - Orbea Orca Aero Carbon OMX disc, monocoque construction, HS 1,5", BB 386, powermeter compatible, Thru Axle 12mm x 142mm rear, thread M12x2 P1, Speed release compatible, internal cable routing, EC/DC compatible.
FORK - Orbea Orca Aero OMX ICR, full carbon, 1-1/8" - 1,5" tapered head tube compatible, Thru axle 12x100mm, thread M12x2 P1, Speed release compatible dropout.
STEERER TUBE - FSA 1-1/2" Integrated Aluminium Cup
DRIVETRAIN
CRANKSET - Shimano Dura-Ace R9200 36x52t
Options - Shimano Dura-Ace R9200-P 36x52t Powermeter
- Shimano Dura-Ace R9200 36x52t with left side 4iiii Powermeter
SHIFTERS - Shimano R9270
CASSETTE - Shimano Dura-Ace R9200 11-30t 12-Speed
Options - Shimano Dura-Ace R9200 11-34t 12-Speed
REAR DERAILLEUR - Shimano Dura-Ace Di2 R9250
FRONT DERAILLEUR - Shimano Dura-Ace Di2 R9250
CHAIN - Shimano CN-9100
COCKPIT
HANDLEBAR - Integrated Bar and Stem OC SH-RA10, Road Aero Carbon, Reach 80, Drop 125
BRAKES
BRAKES - Shimano R9270 Hydraulic Disc
ROTORS - 160mm Front /140mm Rear
Options - 160mm Front /160mm Rear
- 140mm Front /140mm Rear
WHEELS
WHEELS - Oquo Road Aero RA57LTD
Options - Oquo Road Performance RP45LTD
- Oquo Road Performance RP35LTD
- Oquo Road Performance RP50LTD
TIRES - Vittoria Corsa Pro Speed 29-622 TLR wide rim G2.0 OEM HP
FRONT WHEEL AXLE - Orbea Thru Axle 12x100mm M12x2 P1 Lite
REAR WHEEL AXLE - Orbea Thru Axle 12x142mm M12x2 P1 Lite
COMPONENTS
SEATPOST - OC Road Aero RA10 Carbon Ultralight, SB0/25, w/Micro tilt adjustment
SADDLE - Fizik Vento Antares R1 Carbon Rail 140mm
ACCESSORIES
HANDLEBAR TAPE - Orbea Anti-Slippery/Shock Proof
HYDRATION - OC Aero Bottle RA10 (550ml) + Carbon Cage Kit RA10
STORAGE - OC Aero Toolbox TB01PP
HUB
OQUO HUB - OQUO Q10
We reserve the right to make changes to the product and component information appearing on this site at any time without notice, including with respect to equipment, specifications, models, colours, and materials.
LONG LIVE AERO
It’s hard to beat the sensation of power that comes from a great aero bike. What rider is ambivalent about a machine that is designed to give back free watts? Is there a competitor who doesn’t grasp every last advantage in the battle for speed?
Orca Aero is built for pure speed and efficiency, with aerodynamic shaping, exceptional power transfer, and razor-sharp handling. Its race-focused geometry puts you in the perfect position to push harder, ride faster, and hold nothing back.
Advanced Aerodynamics
Aligning the frame with the airflow, optimising cross-sections, smoothing transitions and making myriad other improvements can significantly reduce drag.
Free Speed
Myriad improvements that all combine to reduce drag by 15W at 40km/h or 28W at 50km/h
Top tube and chainstays
Horizontal top tube and chainstays improve airflow.
Down tube and seat tube
The down tube and seat tube profiles have been aerodynamically optimised for 25-28mm tires.
Reduce turbulence
Single-profile transitions between the head tube and downtube and the seat tube and seat stays reduce turbulence in these areas.
Rear wheel airflow
The drag around the rear wheel has been reduced by aligning the upper seat tube junction with the airflow.
Aerodynamic fork
The new aerodynamically designed fork is optimised for high-profile wheels.
Premium OQUO Wheels
The perfect complement to Orca Aero, whether you prioritise lightness, aerodynamics, or the ideal balance of both.
Modern Aero Solutions
Toolbox behind the front wheel
The age-old question of where to carry essential tools, tubes, and identification. Like the bottle cage, the Toolbox is not only useful but aerodynamically beneficial.
Orca Aero is faster with the bottle in place
Airflow around the downtube rolls seamlessly past the bottle and cage, and nothing impedes the beautiful look of the frame. If you need more carrying capacity, there are standard bottle mounts on the down tube and seat tube.
Power and Precision
There’s no doubt about it—a frame that’s stiff in the right places transfers more of your watts to the rear wheel. Your power, converted to speed. That same stiffness also delivers razor-sharp handling, giving you precise control when it matters most—whether you're cornering at speed or holding your line in a sprint.
Improved Power Transmission
The key to power transmission
There is no doubt about it, a frame that is stiff in the right places transfers more of your watts to the rear wheel. Your power converted to speed.
Precision Handling
Stiffness is needed to transform pedal force into forward motion, but it's also key to handling, providing the direct, confident response you need to carve through corners or stay steady in the sprint.
Advanced Frame Construction
Orbea monocoque carbon
We use the most technologically advanced carbon construction available to make the most sophisticated frame possible – A complex and painstaking process with results you will appreciate in the saddle.
OMX carbon is the pinnacle of carbon fiber bicycle manufacturing
When the constant hunt for improvement in our carbon manufacturing yields results that barely resemble those from a few short years ago, it’s time to change the way we talk about carbon. With the introduction of OMX we are showing riders everywhere the direction of our lightest and stiffest performance racing frames
Dynamic Race Handling
Excellent handling comes from great geometry and ergonomics
Balanced Handling
One of the most important points to consider when determining geometry is that the bike must be easy to ride. Going fast isn’t just a byproduct of good aerodynamics; it requires precise control over the bike.
Shorter wheelbase
Shorter wheelbase is more responsive.
Shorter chainstays
Shorter chainstays for better acceleration.
Size-specific fork
Size-specific fork trail gives improved control no matter what frame size.
Lower stack and bigger bb drop
Lower stack and bigger bb drop give better aerodynamics and stability.
Adaptive Ergonomics
Better Ergonomics improves rider comfort, aerodynamics and control. Which means more speed!
OC SH-RA10 Integrated Cockpit - 313 g
An exceptionally light and aerodynamic integrated cockpit, with fully internal routing, ergonomic tops, and sprint-ready stiffness — all engineered for speed.
Orca Aero OMX seatpost
Our new aero seat post allows up to 25mm adjustment on setback and +/- 10º tilt. The 50mm depth seat post, is lightweight and compact.
ICR road stem
Our sprinter-proof road stem, is available in 7 lengths from 70 to 130mm and ensures a perfect fit and cable integration.
Road handlebar
We have developed one of the fastest, most ergonomic aero handlebars. Available in 4 sizes from 360mm to 420mm, our new 5º flared aero bars and stem give up to 15 degrees of rotation plus a choice of width and reach.
